The NanoPi NEO(abbreviated as NEO) is another fun board developed by FriendlyARM for makers, hobbyists and fans.
-Specification-
CPU: Allwinner H3, Quad-core Cortex-A7 Up to 1.2GHz
DDR3 RAM: 256MB/512MB
Connectivity: 10/100M Ethernet
USB Host: Type-A x 1, 2.54 mm pin x 2
MicroSD Slot x 1
MicroUSB: OTG, for power input
Debug Serial Port: 4Pin, 2.54 mm pitch pin header
Audio input/output Port: 5Pin, 2.0mm pitch pin header
GPIO: 2.54mm pitch 36pin. It includes UART, SPI, I2C, IO etc
Power Supply: DC 5V/2A
PCB Dimension: 40 x 40 mm
Working Temperature: -20? to 70?
Weight: 14g(WITHOUT Pin-headers)
OS/Software: u-boot, UbuntuCore and Android
-Package Content-
1x Nanopi NEO Single Board Computer
1x 16GB TF card
1x Acrylic Case
1x heat sink
1x USB toTTL Serial Cable
1x Micro USB Cable
-Technical Support-
- Please click "WayPonDEV" and ask a question.
- Please leave the message monica#smartfire.cn (f------>@) skype: monica_9122.
- Please leave the message in our forum by forum.youyeetoo.com/.
