NanoPi Duo2 Open Source Allwinner H3 Quad-core Cortex-A7 1.2GHz Single Board Computer with DDR3 512M RAM Onboard WiFi Bluetooth Module Support WiringNP Python for IOT Application Development

-Specification- CPU: Allwinner H3, Quad-core Cortex-A7 Up to 1.2GHz DDR3 RAM: 512M Connectivity: 10/100M Ethernet WiFi: 802.11b/g/n Bluetooth: Bluetooth V4.0 of 1, 2 and 3 Mbps. Camera: OV5640 Key: GPIO Key USB Host: 2.54mm pin x2, exposed in 2.54mm pitch pin header MicroSD Slot x 1 MicroUSB: OTG and power input Debug Serial Interface: exposed in 2.54mm pitch pin header Audio input/output Interface: exposed in 2.54mm pitch pin header GPIO1: 2.54mm spacing 16pin. It includes UART, SPI, I2C, Audio etc GPIO2: 2.54mm spacing 16pin. It includes USB,10/100M Ethernet, IO etc PCB Dimension: 25.4 x 55mm Power Supply: DC 5V/2A Temperature measuring range: -20? to 70? -OS/Software- U-boot?Linux-4.14 / Linux-3.4, Ubuntu 16.04.2 LTS (Xenial) Weight: 7.5g (With Pin-headers) -Package Content- 1 x Nanopi Duo2 512MB RAM Single Board Computer 2 x 16pin single-row pin header 1 x Antenna -Technical Support- Wiki: “https://wiki.friendlyelec.com/wiki/index.php/NanoPi_Duo2”. Please click "WayPonDEV" and ask a question or monica#smartfire.cn (f------>@) skype: monica_9122. Please leave the message in our forum by "forum.youyeetoo.com/".
