uxcell D4MC-5020 Limit Switch, Roller Plunger Micro Momentary Switch Panel Mount 1NC+1NO for CNC Mill 3D Printer Door Switch

Specification: Product Name: Limit Switch Model: D4MC-5020 Actuator Type: Roller Plunger Type Rated Voltage: 5A 125VDC / 10A 250VAC Contact Configuration: 1NC+1NO Body Size: 54 x 42 x 21mm (L*W*T) Mounting Hole Size: 4.2mm (D) Mounting Hole Distance: 25.4mm The roller plunger can be operated in a wide range by employing a cam, Dog, cylinder, or auxiliary actuator. Position detection accuracy is high. Operating Characteristics: OF max.: 600g RF min.: 100g PT max.: 2.0mm OT min.: 6.0mm MD max.: 0.8mm OP: 33.3+/-1.2mm Description: -Intensive ABS plastic shell, sealed construction. -Panel mount, side fixed with better water-proof and oil-proof performance. -Smooth operation with higher OT. -Silver contacts. Easy-to-wire design. -This Limit Switch can be widely used in various mechanical to monitor the position of moving parts of machines and control circuit and auxiliary circuit for terminal limit protection.
