-Specification-
SoC: Allwinner D1
RAM: 1GB DDR3 RAM
Display output interface: Onboard a display output connector
RGB screen signal and MIPI screen signal are connected to 2x20p pin pad(Users can use our screen adapter board to drive the screen of RGB interface orMIPI interface)
Network connections: Onboard 2.4G WIFI+BT module , SMT Antenna , IPEX connector
USB: Onboard a USB-A female connector
Audio: On board speaker driver and its connector; On-board electret microphone circuit
Storage: A SOP8 pad is reserved to connect SPI interface. Components are not weldedby default
Expansion connector: Onboard 30P FPC connector, which can be directly connected to our Mic ArrayR6
GPIO expansion: GPIO is led out through 2x20p 2.54mm pad for user use
LED: Onboard a WS2812 RGB LED; On board a power indicator light
Button: Onboard a RST button; Onboard a user button
System: Tina Linux(Based on OpenWRT 14.07), Debian; YoC (RTOS )
-Package Content-
1x Sipeed RV Dock Allwinner D1 1GB Single Board Computer
