WINGONEER HC-SR04+ Ultrasonic Module Distance Sensor for Arduino UNO MEGA2560 Nano Robot XBee ZigBee - 5pcs
Description:
The HC-SR04+ is a wide-voltage working ultrasonic ranging module. The module dimensions and software are fully compatible with the old version of the HC-SR04 and can be seamlessly switched to the old version of the HC-SR04. The lowest operating voltage as low as 3V allows it to be directly connected to a 3.3V powered MCU.
Specifications:
HC-SR04+ Ultrasonic Sensor
Power Supply :5V DC
Quiescent Current : <2mA
Effectual Angle: <15
Ranging Distance : 2cm - 500 cm
Resolution : 0.3 cm
Mode of Connection: VCC/ trig(T)/ Echo(R)/ GND
(VCC supply 5V, and GND is ground wire. TRIG is trigger control signal input, ECHO is echo signal output.)
Package Included:
5 x HC-SR04+ Ultrasonic Module Distance Sensor
