WINGONEER trademark Reg.NO:4747611
WINGONEER ESP32 Rev1 WiFi & Bluetooth Battery & DHT11 Soil temperature and humidity sensor module
Specifications:
FLASH: QSPI flash/SRAM, up to 4 x 16 MB
SRAM: 520 kB SRAM
KEY: BOOT and reset
switch: System power switch
Power indicator lamp: red
USB to TTL: CP2102
modular interface: SD card?UART?SPI?SDIO?12C?LED PWM?TV PWM?I2S?I2C?IRGPIO?capacitor touch sensor?ADC?DACLNA pre-amplifier
on-chip sensor: Hall sensor?temperature humidity sensor
on-board clock: 40MHz crystal oscillator
working voltage: 2.3V-3.6V
working current: about 130mA
working temperature range: -40? ~ +85?
environment temperature range: normal temperature
size: 193mmx29.5mmx1.6mm
Power Supply: USB 5V/1A
Power Supply: 18650 battery
WIFI: Description
Standard: FCC/CE/TELEC/KCC/SRRC/NCC
protocol: 802.11 b/g/n/e/i (802.11n?speed up to150Mbps)A-MPDU and A-MSDU polymerization?support 0.4?S Protection interval
frequency range: 2.4GHz~2.5GHz(2400M~2483.5M)
Transmit Power: 22dBm
communication distance: 300m
Bluetooth: Description
protocol: meet bluetooth v4.2BR/EDR and BLE standard
radio frequency: with -98dBm sensitivity NZIF receiver Class-1,Class-2&Class-3 emitter AFH
audio frequency: CVSD&SBC audio frequency
Software specification: Description
wifi Mode: Station/SoftAP/SoftAP+Station/P2P
security mechanism: WPA/WPA2/WPA2-Enterprise/WPS
Encryption Type : AES/RSA/ECC/SHA
firmware upgrade: UART download/OTA?Through network/host to download and write firmware?
Software Development: Support cloud server development /SDK for user firmware development
networking protocol: IPv4?IPv6?SSL?TCP/UDP/HTTP/FTP/MQTT
User Configuration: AT + Instruction set, cloud server, android/iOSapp
OS: FreeRTOS
Package include:
1 x sensor module
