WINGONEER 1.44 Inch TFT LCD 65K Color 128x128 Display Screen SPI Serial Port Module ST7735 for 51 ARM Arduino
Feature:
Display Size: 1.44 inch
Material: TFT LCD
Resolution: 128 x128 display
Control chip: ST7735
Display area: 25.5x26.5mm
Physical size: 30.0x46.5mm
Interface type: SPI interface
Number of pins: 8PIN
Working voltage: 2.8-3.3V
Working temperature: -20°C~70°C
Interface definition:
1: GND Power ground
2: VCC Power input
3: SCL SPI clock input
4: SDA SPI data input
5: RES Reset
6: DC Data/command selection foot
7: CS Chip select signal, low level active
8: BLK Backlight control, the default can be left floating, low level to turn off the backlight.
Package includes:
1 x TFT display module
