waveshare 1.8inch LCD Display Module 128x160 Pixels Embedded Controller Communicating via SPI Interface. RGB, 65K Display Color with Examples for Raspberry Pi/Jetson Nano/Arduino

Overview This is a general LCD display Module, 1.8inch diagonal, 128x160 pixels, with embedded controller, communicating via SPI interface.
Features SPI interface, requires minimum GPIO for controlling Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/Arduino/STM32)
Specifications Driver: ST7735S Interface: SPI Display color: RGB, 65K color Resolution: 128x160 Backlight: LED Operating voltage: 3.3V/5V
Interface VCC ---Power (3.3V/5V input) GND---Ground DIN ---SPI data input CLK---SPI clock input CS---Chip selection, low active DC---Data/Command selection (high for data, low for command) RST---Reset, low active BL---Backlight
LCD and the controller
ST7735S is a 132*162 pixel LCD, and this product is a 128*160 pixel LCD, so some processing has been done on the display: the display starts from the second pixel in the horizontal direction, and the first pixel in the vertical direction. Start to display, so as to ensure that the position corresponding to the RAM in the LCD is consistent with the actual position when displayed. The LCD supports 12-bit, 16-bit and 18-bit input color formats per pixel, namely RGB444, RGB565, RGB666 three color formats, this routine uses RGB565 color format, which is also a commonly used RGB format The LCD uses a four-wire SPI communication interface, which can greatly save the GPIO port, and the communication speed will be faster.
Online Document/User Manual: //bit.ly/3CtXZV6
Package Content 1.8inch LCD Module x1 PH2.0 20cm x1
