VU Meter Header, VU Meter Header VU Meter with Blue LED Backlight High Accuracy Pointer Power Meters Header, Audio

Specification:
Item Type: VU Meter Header
Pointer Material: Zinc White Copper
Pointer Color: Red
Pointer Swing Direction: From left to right.
Length of Pointer from Needle End to Shaft Center: Approx. 30mm / 1.18in
Pointer Width: 0.45 ± 0.05mm
Upper Cover Material: PMMA
Electric Meter Installation Position: Vertical
Backlight Board: Blue LED, 3.0 - 3.2V 20mA.
Maximum Current Sensitivity: 500uA ± 10%
Internal DC Impedance: 650 ? ± 10%

Package List:
1 x VU Meter Header
