Visionis VIS-7001 Doorbell Type Exit Button for Door Access Control with LED, NC, C and NO Outputs

Tail configuration: Nickel-plated brass terminals Head shape: Flat Round Switch Type for Choice 1 OC(NO+NC) 2 OC(NO+NC) 1 OC(NO+NC)+LED 2 OC(NO+NC)+LED 1 OC(NO+NC)+LED COLOR CHANGE Switch Specifications: 500ma/DC-12V LED Supply Voltage: DC-12V Mechanical life: 200,000 times or more Electrical life: 100,000 times or more Protection class: IP65 Operating stroke: Approximately 2.2 mm Panel thickness: 1~8 mm Shell material: Stainless steel ROHS: Comply with ROHS Total length: < 30 mm Mounting Hole Size: 23 mm Led lifetime: 40000 hours Dimension Of Plate: 114L × 69.40W × 5.4H mm LED Color: Blue VIS-7001 Door Bell Type Request to Exit Button for Door Access Control Attention: This exit button is meant for indoor use. This Exit button does not have a delay
