uxcell 8mm Hall Effect Liquid Water Flow Sensor Switch Flowmeter Counter Meter 1_2-12Lmin SEN-CL08C

Descriptions: 1.Suitable for 8mm inner diameter hose. 2.Water Flow Switch adopts a Magnetic Reed Switch and a movable magnet which is fixed inside the water pipe. When water flows in the pipe, the magnet will detect the water flow and make the reed switch close or open. 3.Mainly used for water heater, boiler, water dispensers, coffee machines, hot card machines, steam equipment, water system, the campus card sales, selling self-help water systems, water treatment equipment, cooling systems, mechanical equipment, instrumentation. Specifications: Product Name: Water Flow Sensor Material: Brass(Shell) Liquid Temperature: Not More Than 60C Flow Range: 1.2-12L/min Connector Size: 8mm Max Switch Voltage: DC250V Max Contact Rating: 70W Max Current: 10mA Maximum Water Pressure: 1.75MPa Cable Length: 33cm Size: 81mm x 21mm x 26mm(L*W*H) Ingress Protection Rating: IP65 Color: Brass Tone Net Weight: 115g Package Included: 1 x Water Flow Sensor Note: 1. Installed in accordance with flow direction in the of product, otherwise there is no signal output. 2. A filter screen must be installed at the inlet of the sensor, in order to avoid particles and debris entering the sensor.
