UTP 12Port Cable Rack Network Cable Rack CAT6A RJ45 Ethernet Network Data Patch Panel Without Bracket T568A and T568B Wiring

Features: 1. Standard T568A and T568B wiring, with good performance and high reliability. 2. The shell material of the binding post is polycarbonate, flame retardant. 3. PPO+PC injection molding, in line with international standards for practicality. 4. 8-pin pin contact material is 3um gold-plated, and the number of insertions and withdrawals is not less than 800 times. 5. The insulation resistance is not less than 1000M? under normal atmospheric pressure. Specification: Condition: 100% brand new Item Type: UTP CAT6A 12port network cable rack Material: Plastic, cold rolled steel Color: As Pictures Shown Specification: 12 ports Process: Machining Insertion and Removal Times: 800 (times) Applicable Cable Type: 22-26AWG Scope of Application: Network wiring Terminal Material: Phosphor bronze nickel plated, the number of insertion and extraction is not less than 300 times. Eight-Pin Material: Phosphor bronze gold-plated, the number of insertion and extraction is not less than 800 times Contact Resistance: Not more than 2.5m? under normal atmospheric pressure Insulation Resistance: Not less than 1000M? under normal atmospheric pressure Dielectric Strength: DC 1000V (AC, 750V) without breakdown and arcing within 1 minute Design Standard: Design and manufacture according to international standard ISO/IEC11801; TIA/EIA568 Product Certification: for FLUKE test Package List: 1 x UTP CAT6A 12Port Network Cable Rack 2 x Cable Tie 4 x Screw
