Advantage: Designed for Metal Frame drill a hole, then install it directly Testing to 1000000 cycles High-Temperature Painted, Duable and Beatiful Artical CE Certificate by European Union, MA Certificate by China Public Security office
Specifications: Fail safe, NC mode (Unlocked when power is removed) Case Size (LxWxD): 85.5x25.5x39.5mm (3-23/64" x 1" x 1-9/16") Faceplate Size (LxWxD): 123x31.7mm (4-27/32" x 1-1/4") Strike Opening(LxWxD): 36.6x16x16.6(mm) (1-7/16" x 5/8" x 21/32) Latchbolt Projection: 19.1mm (3/4") Face Plate Material: 304 Stainless Steel force structure Lock Material: Zinc alloy (baking varnish by high temperature) Holding Force: 1000kg Voltage: 12VDC Current: 320mA Suitable For: Wooden Door, Metal Door, PVC Door Surface Temperature: Within +20? / 68? Suitable Temperature: -10?~+55?(14?-131F) Operating Humidity: 0~90%(non-condensing) Face plate Housing: Painted Steel Lock Tongue: Surface by coating nickel Function: Built-out MOV Weight: 0.34kg / 0.75lb
Package include: 1 x Electric Lock 1 x Manual
Attention: Before placing order, please check the size of your doors frame to avoid wrong purchase Strike lock are designed for use with mortise or cylindrical type locksets which need buy separate.
