Specification:
Model: DH48S-1Z
Working mode: Power-on delay
Time range: 0.01S-99H99M
Delay error: ?1%
Rated voltage: AC 220V
Rated current: 10A
Number of contacts: 1 group of delay contacts with reset pause
Contact load: Medium power
Contact capacity: AC 250V 3A resistive
Contact switching current: 10A
Contact switching voltage: 220V
Contact life: 100000 times
3C rated voltage range: <36V
Dimensions: 60*48*100mm / 2.36*1.89*3.94in
Package weight: Approx. 205g/7.2oz
Package list:
1 * Digital Delay Timer Relay
Note:
1. Due to the difference between monitors and light effects, the pictures may not reflect the actual color of the item.
2. Please allow slight error due to manual measurement. Thanks for your understanding.
