DMWD Low cost single phase solid state relay SSR-60AA
Input voltage 80-250V AC
Load voltage 24-380V AC
Load current 60Amp
60A 80-250V AC to AC solid state relay (SSR) features high structural strength, good impact resistance, and strong shock resistance. The SSR offers a reliable switching the commercial and industrial loads, such as computer peripheral interface device, printing machine, molding machine, food machine, packaging machine, and so on.
- Built in RC absorption
- Photoelectric isolation
- SCR output
- LED indicator for operation status
- Panel mount
- Zero-crossing switch type
- UL Approved, CE Compliant to EN60950-1
Note:
* When the load current is higher than 10A, a heat sink must be installed to the solid state relay, or the SSR relay should be mounted on a metal base plate with heat dissipation effect, and the thermal grease is applied between them.
* When the load current is 40A or more, a fan cooling radiator or water cooling radiator must be equipped.
* Heat sink is included.
Package Content:
1 x Solid State Relay
1 x All Aluminium Heat Sink
Size/Weight:
SSR(60x45x23mm/100g)
Heat Sink(78*50*50mm/80g)
Warranty:
Free new replacement in 5 years, Have faith in quality
