Weight: 9g
Display color: Red/Blue/White/Yellow/Green
Display mode: Three 0.36 LED digital tube
update rate: About 500 ms/time
Physical size: 35mm*23mm*20mm (L*W* H)
Opening size: 32 x 21 mm (L*W)
Power supply: Don't need the power supply, direct use of the test voltage as a power supply
Lead wire length: 9.5 cm
The minimum input: 3.2V
The maximum input: 30V
Measurement range: DC3.2 - 30.0V
Operation temperature: -10 degrees~65 degrees
Measurement accuracy: ± (1% + 2 Digit)
Red line:Power Supply +,Measure Voltage +,(3.2-30V DC)
Black line:Power Supply -, Measure Voltage-
Display color: Red/Blue/White/Yellow/Green
Display mode: Three 0.36 LED digital tube
update rate: About 500 ms/time
Physical size: 35mm*23mm*20mm (L*W* H)
Opening size: 32 x 21 mm (L*W)
Power supply: Don't need the power supply, direct use of the test voltage as a power supply
Lead wire length: 9.5 cm
The minimum input: 3.2V
The maximum input: 30V
Measurement range: DC3.2 - 30.0V
Operation temperature: -10 degrees~65 degrees
Measurement accuracy: ± (1% + 2 Digit)
Red line:Power Supply +,Measure Voltage +,(3.2-30V DC)
Black line:Power Supply -, Measure Voltage-
