Servo Driver HAT 16Channel 12bit I2C Interface PWM Outputs for Jetson Nano Raspberry Pi ZeroZero WZero WH2B3B3B+4B Supports SG90 MG90S MG996R etc XYGStudy

Overview Needless to say, the Raspberry Pi is powerful enough in most cases, yet it's not that good at providing precise PWM output. You may have tried to control a robotic arm or a hexapod walker by using the Pi, but finally get frustrated due to the limited number of PWM outputs and the jittering servo. Now you get a new option to bring your ideas to life, we prepare this useful Servo Driver HAT for you. Features Standard Raspberry Pi 40PIN GPIO extension header, compatible with Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+/4B and later version, Jetson Nano I2C controlled, using only 2 pins Up to 16-Channel servo/PWM outputs, 12-bit resolution for each channel (4096 scales) Integrates 5V regulator, up to 3A output current, can be powered from battery through VIN terminal Standard servo interface, supports common used servo such as SG90, MG90S, MG996R, etc. Reserved I2C control pins, allows to work with other control boards Comes with development resources and manual (examples in python like Bluetooth/WiFi remote control) Specifications Power supply: 5V (Pi connector) OR 6V~12V (VIN terminal) Servo voltage: 5V Logic voltage: 3.3V Driver: PCA9685 Control interface: I2C Dimension: 65mm x 30mm Mounting hole size: 3.0mm Package Contains : Note: Raspberry Pi and servo in the photos are NOT included. Servo Driver HAT x1 RPi screws pack (2pcs) x1 For more details you may need to know, pls firstly send me message via Amazon, I will then send attached link including User Guide for you, thank you for patience :)
