Setting of Working Mode:
1. Momentary :Reference product image.
2. Toggle :Reference product image.
3. Latched :Reference product image.
4. 2CH momentary 2CH Toggle : pressing 4 times the learning key button on the receiver board(Led indicator on receiver board will signaling simultaneously ),then press any of the remote button , signaling 3 times by remote's LED indicator informs about setting successfully .
5. 2CH Momentary 2CH Latched : pressing 5 times the learning key button on the receiver board ( Led indicator will signaling simultaneously ),then press any of the remote button , signaling 3 times by remote's LED indicator informs about setting successfully.
6. 2CH Toggle 2CH Latched : pressing 6 times the learning key button on the receiver board( Led indicator will signaling simultaneously ),then press any of the remote button , signaling 3 times by remote's LED indicator informs about setting successfully.
7. 2CH Latching 2CH Latched : pressing 7 times the learning key button on the receiver board( Led indicator will signaling simultaneously ),then press any of the remote button , signaling 3 times by remote's LED indicator informs about setting successfully.
8. Deleting existing remote controls data: pressing 8 times the learning key button on the receiver board , the LED indicator will flash for eight times , the existing remote controls are deleted successfully.
Receiver:
Working Voltage & Quiescent Current: DC12V & 5mA
Working Frequency: 433Mhz
Output Current: ?10A
Receiving Sensitivity: >104dBm
Function option: Momentary / Toggle / Latched
Modulation Mode: ASK
Matching Mode: Intelligent Learning code
Output Mode:Dry contact / Voltage output
Transmitter:
RF Frequency: 433 MHz.
IC Type: Learning Code(1527)
Operating Voltage: DC 3V.
