Feature:
1. Better Sensor: Able to detect temperature and humidity with high accuracy, the transmitter allows for flexible application.
2. Clear Display: LCD screen enables clear digital display as well as more convenient operation to save your time and labour.
3. Reliable Work: Combining dedicated analogue circuit and 10?30V wide voltage input, the temp meter has excellent durability.
4. Simple to Use: You can easily set the parameters through the buttons, and the good dust protection ensures high work safety.
5. Easy to Install: The light weight together with compact size largely simplifies both wall mount and slide rail installation.
Specification:
Item Type: Temperature Sensor
Product Size: Approx. 147 x 88 x 41mm / 5.79 x 3.46 x 1.61in
Power Supply Wiring: Wide voltage 10~30V DC power input.
Product Overview: The transmitter is an industrial wall mounted enclosure with a high degree of protection. The circuit adopts industrial grade microprocessor chip and high accuracy temperature and humidity sensor to ensure excellent reliability, high accuracy and interchangeability of the product. Adopts standard industrial interface 4~20mA analogue signal output, can be connected to on site digital display, PLC, inverter, industrial control host and other equipment, safe and reliable, beautiful appearance, easy installation.
Parameter:
Model RS-WS-120-2D-LCD
DC Power Supply (Default) DC 10~30V
Maximum Power Consumption Current Output 1.2W
Voltage Output 1.2W
A Accuracy Humidity ±2%)60%?25?)
Temperature ±0.4?)25?)
B Accuracy Humidity ±3%(60%,25?)
Temperature ±0.5?)25?)
Temperature Range -40?~+120?, Default -40?~+80?
Humidity Range 0%-
Transmitter Circuit Working Temperature and Humidity -20?~+60?, 0%~95% (NonCondensing)
Probe Operating Temperature -40?~+120?, Default -40?~+80?
Probe Working Humidity 0%-
Term
1. Better Sensor: Able to detect temperature and humidity with high accuracy, the transmitter allows for flexible application.
2. Clear Display: LCD screen enables clear digital display as well as more convenient operation to save your time and labour.
3. Reliable Work: Combining dedicated analogue circuit and 10?30V wide voltage input, the temp meter has excellent durability.
4. Simple to Use: You can easily set the parameters through the buttons, and the good dust protection ensures high work safety.
5. Easy to Install: The light weight together with compact size largely simplifies both wall mount and slide rail installation.
Specification:
Item Type: Temperature Sensor
Product Size: Approx. 147 x 88 x 41mm / 5.79 x 3.46 x 1.61in
Power Supply Wiring: Wide voltage 10~30V DC power input.
Product Overview: The transmitter is an industrial wall mounted enclosure with a high degree of protection. The circuit adopts industrial grade microprocessor chip and high accuracy temperature and humidity sensor to ensure excellent reliability, high accuracy and interchangeability of the product. Adopts standard industrial interface 4~20mA analogue signal output, can be connected to on site digital display, PLC, inverter, industrial control host and other equipment, safe and reliable, beautiful appearance, easy installation.
Parameter:
Model RS-WS-120-2D-LCD
DC Power Supply (Default) DC 10~30V
Maximum Power Consumption Current Output 1.2W
Voltage Output 1.2W
A Accuracy Humidity ±2%)60%?25?)
Temperature ±0.4?)25?)
B Accuracy Humidity ±3%(60%,25?)
Temperature ±0.5?)25?)
Temperature Range -40?~+120?, Default -40?~+80?
Humidity Range 0%-
Transmitter Circuit Working Temperature and Humidity -20?~+60?, 0%~95% (NonCondensing)
Probe Operating Temperature -40?~+120?, Default -40?~+80?
Probe Working Humidity 0%-
Term
