Specification:
Material: ABS, PC
Scanning Mode: CMOS Image Based Scanning
Resolution: 752 x 480 Pixels
Light Source: 265LX (130NM)
Light Source Type: LED (650NM))
Scanning Speed: 200 Times/S
Accuracy: ?5mil
Printing Contrast: ?30%
Maximum Power: 1.33W
Voltage: (3.3V-5V) ± 5%
Maximum Current: 330mA
Sleep Current: 50uA
Standby Time: 30 Seconds Into Standby
LED Indication:
Connection LED: Green
Scanning Indicator: Red
Data Interface: Support USB, RS232 Interface
System: for WINDOWS, for LINUX
Reading Distance: Approx. 20cm/7.9in
Communication Distance: Wireless 80M In The Open Distance
Battery Alarm: Buzzer sounds five times in a row.
Scanning Width: 30MM at Scanner Window, 220MM at 200MM
Scanning Angle: Rotate 30°, Tilt ±65°, Deflect ±55
Alerting Method: Buzzer, LED Indicator Light
Usage: 63000 Times
Housing Material: ABS + PC
Operating Temperature: 0?-50?(32°F-122?)
Storage Temperature: -40?-60?(-40?-140?)
Relative Humidity: 5%-95% ( Non Condensing )
Peripheral Illumination: 0-100000lx
Electrostatic Protection: ±8KV ( Contact Discharge ), ±15KV ( Air Discharge )
Drop Height: Approx. 1.5m/4.9ft
IP Rating: IP54
Decoding Capability:
2D: PDF417, MICROPDF417, QR CODE, DATAMATRIX
1D: UPC A, UPC E1, UPC EO, EAN 13, EAN 8, ISB(BOOKLAND EAN), ISSN, CODE 39, CODE 39 FULL ASCII, CODE 32, TRIOPTIC CODE 39, INTERLEAVED 2 OF 5, INDUSTRIAL 2 OF 5, CODABAR (NW7), CODE 128, ISBT 128, CODE 93, CODE 11 (USD 8), MSI, for PLESSEY, UK, for PLESSEY, UCC, EAN 128, for CHINA POST, for CHINA FINANCE, GS1 DATABAR (FORMERLY RSS) VARIANTS
Battery: Rechargeable Lithium Battery 2000mah x 1 ( Shipped With Built In Battery )
Packing List:
1 x Bar Code Reader
1 x Connection Cable
1 x Wireless Receiver
1 x Manual
