Orange Pi PC 1GB DDR3 AllWinner H3 Quad-core Cortex-A7 Single Board Computer, Development Board Run Orange Pi/Android/Ubuntu/Debian(Pi PC)

Hardware Specification CPU: H3 Quad-core Cortex-A7 H.265/HEVC 4K GPU: Mali400MP2 GPU @600MHz, Supports OpenGL ES 2.0 Memory (SDRAM): 1GB DDR3 (shared with GPU) Onboard Storage Onboard Network: TF card (Max. 64GB), MMC card slot 10/100 Ethernet RJ45 Video Input Audio Input: A CSI input connector Camera: Supports 8-bit YUV422 CMOS sensor interface Supports CIR656 protocol for NTSC and PAL Supports SM pixel camera sensor Supports video capture solution up to 1080p@30fps MIC Video Outputs Audio Output: Supports HDMI output with HDCP Supports HDMI CEC Supports HDMI 30 function Integrated CVBS Supports simultaneous output of HDMI and CVBS 3.5 mm Jack and HDMI Power Source USB 2.0 Ports: DC input, USB OTG input don't supply power Three USB 2.0 HOST, one USB 2.0 OTG Buttons Low-level peripherals: Power button 40 Pins Header GPIO(1x3) pin LED: UART, ground. Power led & Status led Supported OS: Android Lubuntu, Debian Key: IR input.POW Product Size: 85mm x 55mm Weight: 38g
