PoE HAT Product Summary:
This is the
official Raspberry Pi Power Over Ethernet (PoE) HAT for the Raspberry Pi 3 Model B+ single board computer. This small add on accessory may be used to power your Raspberry Pi 3 B+ with an Ethernet cable on a PoE enabled network, eliminating the need for a separate power supply. An 802.3af compliant PoE injector, switch or router (not included) is required to use PoE capability.
Specifications:
- Official Raspberry Pi product
- PoE Class 2 device
- Power over Ethernet 802.3af compliant
- SMPS: Fully isolated Switched-Mode Power Supply
- Input voltage: 36 - 57v
- Output voltage: 5v
- Amps: up to 2.5a
- Includes brushless fan with fan control for cooling
- Plug-and-play installation with Raspberry Pi 3 B+ (not included)
Package Contents:
The PoE HAT package contains the following items:
- 1 PoE HAT for use with Raspberry Pi 3 B+ (and onward) SBC
- 4 Mounting screws to attach the HAT to the RPi board
- Does not include Raspberry Pi 3 Model B+
- Sourced from U.S. authorized/official distributors
Applications:- Educational / Maker use
- IoT (Internet of Things) devices
- Communications and network devices
- Applications where PoE is available and preferable
Raspberry Pi is a trademark of the Raspberry Pi Foundation.
