NTE Electronics NTE989 Integrated Circuit General Purpose Phase Lock Loop 14 Lead DIP Package 8 Amp Power Supply Current 12V Supply Voltage

The NTE989 is a general purpose Phase Locked Loop (PLL) in a 14–Lead DIP type package containing a stable, highly linear voltage controlled oscillator for low distortion FM demodulation, and a double balanced phase detector with good carrier suppression. The VCO frequency is set with an external resistor and capacitor, and tuning range of 10:1 can be obtained with the same capacitor. The characteristics of the closed loop system–bandwidth, response speed, capture and pull in range– may be adjusted over a wide range with an external resistor and capacitor. The loop may be broken between the VCO and the phase detector for insertion of a digital frequency divider to obtain frequency multiplication.
