NOYITO 2 Channel Relay Module With Isolated Optocoupler 5V 12V 24V High Low Level Trigger Module Triggered (Pack of 2) (5V, Red)

Description : 1. The module uses high quality relay , normally open interfaces Maximum load : AC 250V/10A, DC 30V/10A; 2. The power indicator (green) , relay status indicator (red) 3. Module size : 50mm * 41mm * 18.5mm (L * W * H) 4. Has four mounting bolts holes , hole 3.1mm, 44.5mm * 35.5mm pitch Technical Parameters: 5V relay version: Quiescent current: 5mA Maximum current: 190mA Trigger current: 2-4mA Low level trigger voltage: 0-1.5V High level trigger voltage: 2.5-5V 12V relay version: Quiescent current: 5mA Maximum current: 80mA Trigger current: 2-4mA Low level trigger voltage: 0-4V High level trigger voltage: 4.5-12V 24V relay version: Quiescent current: 5mA Maximum current: 50mA Trigger current: 2-4mA Low level trigger voltage: 0-8V High level trigger voltage: 8.5-24V Module Interface: 1. DC +: positive power supply 2. DC-: negative power supply 3. IN1: 1 channel signal to trigger side , you can set a high or low level control relay 4. IN2: 2 -channel signal to trigger side, you can set a high or low level control relay Relay Outputs: 1. NO1: 1-channel normally open interface 2. COM1: 1-channel relay common interface 3. NC1: 1-channel normally closed interface 4. NO2: 2-channel normally open interface 5. COM2: 2-channel relay common interface 6. NC2: 2-channel normally closed interface Pacakge Included: 2pcs NOYITO 2 Channel Relay Module
