Newest Raspberry Pi 8-Channel Relay Expansion Board 5V Power Relay Module for Raspberry Pi 4 3 2 Model B+ B Jetson Nano @XYGStudy

The RPi Relay Board (B) is an expansion board with 8-ch relays for Raspberry Pi. It gives your Pi the ability to control high voltage products such as home appliances. Features Standard Raspberry Pi 40PIN GPIO extension header, Supports Raspberry Pi A+/B+/2B/3B/3B+/4B and later versions, Jetson Nano High quality relays, loads up to 5A 250V AC or 5A 30V DC Photo coupling isolation, prevent interference from high voltage circuit Standard rail mount bottom case Onboard LEDs for indicating relays status Relay control pin selection jumper, allows to control the relays by custom pins other than the default pins Reserved control Interface, allows to work with controllers like PLC Comes with development resources, including examples in wiringPi, bcm2835, python, python-bottle (webpage control), and crontab (cron job) Specifications Power supply voltage: 5V Trigger signal: 3.3V/5V Relay channels: 8-ch Contact form: SPDT-NO,NC Closed current: 6mA (per channel) Connector: screw terminal block Dimension: 232 × 72 (mm) Mounting hole size: 3.0mm Package Contains: RPi Relay Board (B) x1 Rail mount bottom case x1 Screws pack x1 For more resources you may need, pls contact me via Amazon message, i will send you then via attachment.
