Classic duckbill shape toggle switches infused with modern colored glow.
The duckbill toggle switch is designed for 12vDC single-pole, single-throw circuitry. Rated 15A with illuminated colors available. Unlike most other illuminated switches, the duckbill toggle bulb is not overly bright; the glowing handle is only readily seen in darker cockpits.
Features
- QUICK INSTALLATION: The duckbill toggle switch has a threaded body and removable nut that allows for quick through-panel mounting. Simply tighten the nut overtop the face plate. Mounting Hole Diameter: 0.47? (12mm)
- EASY TO USE: Lighted toggle has spade terminals for easy connecting. SPST 3 pin design has a source input, a load output, and a ground for the incandescent bulb. The switch illuminates when the actuator is ON.
- COMPACT: Short duckbills are also the most compact of all toggle type switches, measuring only 0.472" in body width and 1.17" in body length, with a handle measuring 0.70" from the top of the switch's mounting threads. The entire switch, including the duckbill toggle and spade terminals, is only 2.075" in length.
