Melopero AMG8833 Grid Eye IR Array Breakout

ONLY PYTHON LIBRARY AVAILABLE. The AMG8833 is a High Precision Infrared Array Sensor from Panasonic. It can detect temperatures on a two-dimensional area, 8 × 8 (64 pixels), in the range 0 °C to 80 °C with a typical accuracy of ±2.5 °C ±4.5 °F and can detect a human from a distance of 7 m or less. This breakout board includes a 3.3V regulator and level shifting circuitry, this makes it compatible with both 3.3V and 5V power and logic. The sensor communicates over I2C bus, the default address is 0x69. Soldering the jumper on the back of the board, you'll set 0x68 as the I2C address. We wrote a Python 3 library and some examples (available the melopero GitHub page ) to quickly start with a Raspberry Pi. Check out schematics and datasheet for more technical specs. Pinouts: VIN: Input power pin. This pin is connected to the onboard 3.3V regulator, you can apply both 3.3V and 5V. GND: Ground pin SDA: I2C Serial DAta line, compatible with both 3.3V and 5V logic. SCL: I2C Serial CLock line, compatible with both 3.3V and 5V logic. INT: Interrupt output pin, active low (interrupt function is NOT implemented in our Python 3 library). 3V3: This pin is connected to the output of the on-board 3.3V regulator (MIC5225-3.3). Dimensions: 21.6 mm × 25 mm x 4.85 mm (max height)
