Features:
Output current level selectable by DIP switch
180~295VAC input only
Built-in active PFC function
Protections: Short circuit / Over voltage / Over temperature
Cooling by free air convection
Fully isolated plastic case
No load power consumption <1W
Class II power unit, no F.G.
Logarithm or linear dimming curve selectable (meet IEC62386-207)
Built-in 0~10Vdc and PWM signal dimming function
Power supplies synchronization function up to 10 units
Built-in 12V/50mA auxiliary output (40W/60W only)
Temperature compensation function by external NTC (40W/60W only)
Suitable for indoor LED lighting applications
3 years warranty
General Specification:
AC input voltage range:180~295VAC; 254~417VDC
AC inrush current (Typ.):Cold start, 20A at 230VAC
Short circuit protection:Constant current limiting, recovers automatically after fault condition is removed
Over voltage protection:110~130VDC
Over temperature protection Range:90OC ±10OC (RTH2)
Over temperature protection Type:Shut down o/p voltage, re-power on to recover
Setup, rise, hold up time:1000ms, 80ms, 16ms at full load and 230VAC
Withstand voltage:I/P-O/P: 3.75kVAC
Working temperature:-30~+60ºC (refer to output derating curve)
Safety standards:UL8750, ENEC EN61347-1, EN61347-2-13, EN62384 approved
DALI standards:NONE
EMC standards:EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547
Dimension (LxWxH)(mm):123.5x 81.5x 23
