Makeblock MP8049S 4-Path DC Motor Driver for MegaPi Pro

Technical specifications: Motor driver: MP8049S Number of motor channels: 4 Minimum operating voltage: 6V Maximum operating voltage: 12V Logical voltage: 5V Rated operating current of each channel: 3A Peak operating current: 5.5A Dimensions: 39 mm x 39 mm ( length× height) Features: - This MP8049S 4-path DC motor driver is designed for MegaPi Pro with 4 DC motor ports, so it can drive 4 25 DC motors/4 37 DC motors/4 electromagnetic valves. - ""H"" Shape structure driver with 4 mosfets which can generate 4 kinds of working station: forward rotation, reverse rotation, braking and coasting. - Supports motors with the operating voltage range of 6V to 12V, the operating current is 3A when the power supply is 12V and the maximum will be 5.5A. - Equipped with overvoltage, overcurrent, overtemperature protection, and the transient voltage suppressor (TVS) protection which ensures safe application. - It supports Arduino IDE, Raspberry Pi python3, mBlock graphical programming. Coding Demo: Arduino IDE: https://github.com/Brandonwong11/makeblock-MegaPiPro/tree/master/examples/Arduino/MegaPi_Pro_4DC_Motor_Driver_V1.0 mBlock: https://github.com/Brandonwong11/makeblock-MegaPiPro/blob/master/examples/mBlock3/MegaPi%20Pro%204DC%20Motor%20Driver%20V1.0.sb2 and https://github.com/Brandonwong11/makeblock-MegaPiPro/blob/master/examples/mBlock5/MegaPi%20Pro%204DC%20Motor%20Driver%20V1.0.mblock Raspberyy Python3: https://github.com/Brandonwong11/makeblock-MegaPiPro/blob/master/examples/Python3/DCMotor.py
