Makeblock MegaPi Pro ATMEGA2560-16AU Micro Control Board with Servo Motor Driver Step Motor Driver for Arduino Raspberry Pi

Description: MegaPi Pro is an ATMEGA2560-16AU based micro control board 100% compatible with Arduino IDE and many shields designed for it.Faster transfer rates and more memory for storing coding. It provides powerful programming functions and a maximum output power of 120 W. With four port jacks, one 4-way DC motor expansion interface, one RJ25 expansion board interface, and one smart servo interface, MegaPi Pro is highly expansible. Its strong expansion ability enables it to meet the requirements of education, competition, entertainment, etc. MegaPi Pro can be easily installed on Raspberry Pi, and connected through serial ports. With the corresponding programs, Raspberry Pi can be used to control electronic modules, such as motors and sensors. Technical Specifications: Microcontroller: ATMEGA2560-16AU Input voltage: DC 6–12 V Operating voltage: DC 5 V Serial port: 3 I²C interface: 1 SPI interface: 1 Analog input port: 16 DC Current per I/O Pin: 20 mA Flash memory: 256 KB SRAM: 8 KB EEPROM: 4 KB Clock speed: 16 MHz Dimensions: 87 mm x 63 mm (width × height) Features: Four motor driver interfaces for adding encoder motor driver and stepper motor driver, and thus drving DC motors, encoder motors, and stepper motors. One wireless communication interface for adding modules, such as Bluetooth module or 2.4G module. One smart servo interface that enables the expansion of four DC motors. One RJ25 expansion board interface that enables the expansion of eight RJ25 interfaces. Three M4 installation holes that are compatible with Raspberry Pi. Overcurrent protection. Coding Demo: Arduino IDE:https://github.com/Makeblock-official/Makeblock-Libraries Raspberry Python3: https://www.yuque.com/makeblock-help-center-zh/mcode/pln1gg mBlock: https://www.mblock.cc/en-us & http://docs.makeblock.com/diy-platform/en/electronic-modules.html for more information.
