LYCEBELL LC-570T-APP Intelligent Digital Clamp Multimeter
Auto-Ranging 1000A & Logging Date on Mobile Phone Tablet
Specifications:
DC voltage 600mV-600V
AC voltage: 6V/60V/600V
AC/DC current: 60A-400A
Resistance 600?-60M?
Capacitance: 6nF-60mF
Duty cycle: 0.1%~99.9%
Temperature Test: -4-1832 ?
-AILink APP Connect:
Scan the QR code to download the AILink APP first. You can connect to your smartphone for real-time measurements(within 15m).
-Live Wire Test:
The live wires must be separated when testing AC current, otherwise the degrees will always be zero.
-Temp Test:
Put the sensor probe into the temperature field under measurement. Set the rotary switch at the desired ?/? range position, push SELECT to choose ? or ? measurement.
-Auto Power Off(15 mins)
Press REL will show the relative testing and zeroing the clamp tester to obtain more accurate measurement.
Product Features:
?Date Hold
?Diode Test
?Auto Ranging
?Auto Power Off
?MAX/MIN Mode
?Temperate Test
?Continuity Buzzer
?Bright LCD Backlit
?Low Battery Indicator
Package Content:
1 x LC-570S Clamp Multimeter
1 x Test Lead
1 x Temp Probe
1 x Carrying Case
1 x 9V(6F22) Battery
1 x Instruction Manual(English)
100% Satisfaction Customer Service:
Friendly support team, 12 Months Worry-Free Replacement for any defective product due to production process.
