Levenhuk M35 BASE Digital Camera
The Levenhuk M35 BASE Digital Camera is a junior model in the Levenhuk M BASE series. The 0.3Mpx camera allows you to take images with a resolution of 640x480 pixels. The maximum video frame rate is 30fps. The special Levenhuk software (included) allows you to modify the camera settings and process the resulting images and videos.
The camera can be connected to a biological or stereoscopic microscope with a 23.2mm diameter eyepiece tube. To install the camera on microscopes of other diameters, an adapter is needed (sold separately).
The kit includes:
Levenhuk microscope digital camera
USB cable for connection to PC or laptop and power supply
Installation CD with Levenhuk image editing software and the required drivers
User manual and lifetime warranty
Specifications:
Maximum resolution: 640x480
Megapixels: 0.3
Sensor: 1/4'' CMOS
Pixel size: 5.6x5.6
Exposure time, ms: auto
Video recording: yes
Sensitivity, v / lux.sec @ 550 nm: 30@640x480
Application: eyepiece tube of 23.2mm diameter, instead of the actual eyepiece
Image format: *.jpg, *.bmp, *.png, *.tif
Video format: recording: *.wmv, *.avi, *.h264 (Win 8 or later), *h265 (Win 10 or later)
Spectral range: 380-650nm (built-in infrared filter)
Method of exposure: ERS (Electronic Rolling Shutter)
White balance: auto/manual
Exposure control: auto/manual
Software features: image size, brightness, exposure time
USB features: USB 2.0, 480 Mb/sec.
System requirements: Mac OS 10.12, Linux Ubuntu 14.04, Windows XP/Vista/7/8/10 (32bit or 64-bit), CPU IntelCore 2 or above; RAM 2GB, USB port 2.0, CD-ROM.
Software: Levenhuk
Casing: metal
Power supply: via USB 2.0 cable
Operating temperature range: -10... 50C; 14... 122F
