Description:
This product is a new type of energy-saving lighting switch, it adopts high sensitivity detector, integrate circuit and SMT, safe and practical.
Features:
Easy to install. Automatic, convenient, safe and practical. Motion sensor can identify day and night automatically. Wide Detection Range: Made up of up and down, left and right service field. It utilizes human motion infrared rays as control signal sources, when one enters the detection field, it will start the controlled load at once. Motion sensor turns lights ON automatically when motion is detected and OFF after a pre-selected time delay (5s to 6minutes).
Specifications:
Condition: New
Color: Black
Material: ABS
Working Rotation: 180°
Voltage: AC90V~250V
Standard: LVD, EMC, CE, RoHS
IP Rating: Indoor application IP64
LUX Setting: 2-2000lux (adjustable)
Induction Lighting Time: 5s~6min adjustable time
Detection Distance: Approx. 12M, installation 1.8-2.5M height
Weight: Approx. 122g
Package Includes:
1 x motion sensor detector switch
Note:
1. Please allow 1-2mm error due to manual measurement. Thanks for your understanding.
2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.
This product is a new type of energy-saving lighting switch, it adopts high sensitivity detector, integrate circuit and SMT, safe and practical.
Features:
Easy to install. Automatic, convenient, safe and practical. Motion sensor can identify day and night automatically. Wide Detection Range: Made up of up and down, left and right service field. It utilizes human motion infrared rays as control signal sources, when one enters the detection field, it will start the controlled load at once. Motion sensor turns lights ON automatically when motion is detected and OFF after a pre-selected time delay (5s to 6minutes).
Specifications:
Condition: New
Color: Black
Material: ABS
Working Rotation: 180°
Voltage: AC90V~250V
Standard: LVD, EMC, CE, RoHS
IP Rating: Indoor application IP64
LUX Setting: 2-2000lux (adjustable)
Induction Lighting Time: 5s~6min adjustable time
Detection Distance: Approx. 12M, installation 1.8-2.5M height
Load Power: 150 Watts
Wiring:
Brown - live wire
Blue - neutral wire
Red for the output wire
The blue wire is the common wire
Weight: Approx. 122g
Package Includes:
1 x motion sensor detector switch
Note:
1. Please allow 1-2mm error due to manual measurement. Thanks for your understanding.
2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.
