KNACRO DCDC NC Boost Buck Module ADJ 1040V to 038V 6A Max Constant Voltage Constant Current Buck Module

DC-DC numerical control step-up and down module is a digital display of the NC step-up and down module, small size, power, high efficiency, stable work. The module is characterized by the input voltage below, above, equal to the output voltage, the output voltage can be maintained stable, input 10V-40V output 0-38V, current 0.001-6A. With high-speed micro-controller precision measurement and calculation, you can accurately adjust the size of the output voltage and current, built-in 10 groups of storage location, can be stored at any time, call out the parameters, easy to use. With 4-digit 8-segment LED digital display, you can real-time display voltage, current, power, capacity and other parameters. The machine has automatic power output after the power, automatic wheel display parameters and other functions, according to the need to use to open or close. Modular nature: non-isolated step-up and down Input voltage: 10V ~ 40V Output current: 0 ~ 6A Output voltage: 0 ~ 38V Conversion efficiency: up to 92% Operating frequency: 150KHz Short circuit protection: constant current Operating temperature: -40 ? ~ +85 ? Control mode: digital control + digital display Voltage regulation / display resolution: 0.01V Power display Minimum resolution: 0.001W Current regulation / display resolution: 0.001A Capacity Display Minimum resolution: 0.001AH Output ripple: ? 50mV Weight: 116g Size: 100* 80*29 mm?L*W*H? Package Included: 1*DC-DC NC BOOST Buck Module 1*User manual
