KNACRO 8-Channel Low Level Trigger Solid State Relay Module DC-DC Load 5A Switch Control Panel Module (DC 5V)

Using FR-4 double-sided circuit boards.
5A high quality solid state relay.
Input and output are using KF128-3.81 Terminal Block, wiring more convenient.
Use SS8050 1.5A high current transistor for switching transistor, quality is more stable.
PCB has four screw holes.

Power supply: 5V DC.
Trigger: LOW trigger
5V: 0-1.5V DC relay switches (ON), 3-5V above the relay off (OFF), Note: 6V unknown state.
12V: 0-4.5V DC relay switches (ON), 5.5-12V above the relay off (OFF),
24V: 0-8.5V DC relay switches (ON), 10-5V above the relay off (OFF),

Load current: 5-220V DC 5A (DC only).
Board Size: 71 * 68.5 * 25 mm.
Positioning hole spacing: 63.6 * 5.5, Aperture: 3.1 mm.
Using FR-4 double-sided circuit boards.
5A high quality solid state relay.
Input and output are using KF128-3.81 Terminal Block, wiring more convenient.
Use SS8050 1.5A high current transistor for switching transistor, quality is more stable.
PCB has four screw holes.
Wiring Port Description:

DC +: positive power supply DC -: negative power supply
CH1 / CH2: triggering end (0-2V DC Trigger low effective)
