KNACRO 12V 2-Channel Low-Level Solid State Relay modules Solid State relays with Fuse 240V 2A Low-Level Trigger

Solid state relays 12V 240V 2A, output with resistive fuse 240V 2A. Control signal input voltage: 0-5.5V at low state relay OFF; 6-12V high state relay ON. Blue KF301 terminal access control line is more convenient Input Power: DC 12V Size:55 * 33 * 25 mm (L * W * H) Weight: 21.5 g Size:55 * 33 * 25 mm (L * W * H) Weight: 21.5 g Input Power: DC 12V Control signal input voltage: 0-5.5V at low state relay OFF; 6-12V high state relay ON. Module Interface: Input section: DC +: positive power supply (power supply voltage by relay) DC -: negative one CH: relay module signal triggering end (high trigger enabled) High levels and low levels of meaning: High trigger finger trigger signal terminal (IN) and a negative electrode having a positive power supply voltage is usually between the trigger and the positive power source is connected, when the trigger trigger terminal end having a positive voltage or trigger voltage is reached, the relay Be attracted. Trigger voltage signal is low-level trigger finger and negative electrode power between the 0V, or trigger voltage higher than the positive supply voltage, low voltage, low enough to trigger the relay, is usually a cathode power supply and trigger mode trigger terminal connected, so that the relay is attracted. Electrical parameters: Voltage version, the quiescent current, current, voltage trigger, trigger current 1 channel 12V, 0 mA, 10 mA, 0-5.5V, 2mA 2-way 12V, 0 mA, 22.5 mA, 0-5.5V, 2mA
