Jili Online Camera Shield OV2640 2MP Mini Module Image Sensor Part for Arduino UNO

Description: - The OV2640 image sensor features 2 megapixels (1632x1232 pixels) - Small in size, low operating voltage, and provides all the features of a single chip UXGA camera and image processor. - Through the SCCB control, you can output the entire frame, sub-sampling, take the window, and a variety of resolution 10-bit sampling data. - The product UXGA images up to 15 frames per second. - The user can fully control the image quality, data format and transmission mode. Specification: - Standard SCCB interface, compatible with I2C interface - RawRGB, RGB (GRB4: 2: 2, RGB565 / 555/444), YUV (4: 2: 2) and YCbCr (4: 2: 2) output format - Supports UXGA, SXGA, VGA, QVGA, QQVGA, CIF, QCIF and up to 40x30 size - Supports VarioPixel sub sampling mode - ISP with noise cancellation and dead pixel compensation - Support image scaling - Lens loss compensation - Saturation automatic adjustment - Edge enhancement automatic adjustment - Noise reduction automatic adjustment - Sensing array 1632x1232 - Maximum format UXGA IO - voltage 1.7V-3.3V - Analog voltage 2.5-3.0v (internal LDO to power supply 1.2V) - Power consumption TBD sleep<20?A - Temperature operation -30 ? to 70 ? - Stable working 0 ? to 50 ? - Output format (8-bit) - YUV / YCbCr4: 2: 2 RGB565 / 555/444 - GRB4: 2: 2 RGB Data - Optical size 1/4" - Viewing angle 25 Degree - Maximum rate 15fps - SXGA sensitivity 1.3V / (Lux-sec ) - Signal to noise ratio 40dB - Dynamic range 50 dB - View mode Progressive electron exposure 1 line to 1247 lines - Pixel area 2.2 ?m x 2.2 ?m - Dark current 15 mV / s at 60 °C Package Includes: 1 Piece of Mini Module Camera
