GORITE Intel NUC Development USB 2.0 LID

NUC Development USB 2.0 LID Description: The NUC Development LID allows designers to access a USB 2.0 signal pad layout on the top side of the PCB under the Expansion LID. This unit gives designers ample space to add their own daughter card while having easy access to a USB signal. The unit offers a pad layout for one USB signal while having an external USB 2.0 Port. Supports NUC Model Numbers: Maple Canyon (5th Gen Core i3/i5 - Commercial NUCs) i3 SKU: Intel NUC Kit NUC5i3MYHE i5 SKU: Intel NUC Kit NUC5i5MYHE 1 X 8 USB header Rock Canyon (5th Gen Core i3/i5/i7 - Consumer NUCs) i3 short SKU: Intel NUC Kit NUC5i3RYK i3 tall SKU: Intel NUC Kit NUC5i3RYH i5 short SKU: Intel NUC Kit NUC5i5RYK i5 tall SKU: Intel NUC Kit NUC5i5RYH i7 tall SKU: Intel NUC Kit NUC5i7RYH 1 X 8 USB header Swift Canyon (6th Gen Core i3/i5 - Consumer NUCs) i3 short SKU: Intel NUC Kit NUC6i3SYK i3 tall SKU: Intel NUC Kit NUC6i3SYH i5 short SKU: Intel NUC Kit NUC6i5SYK i5 tall SKU: Intel NUC Kit NUC6i5SYH Dual 1 X 4 USB header Pinnacle Canyon & Grass Canyon (Celeron and Pentium - Consumer NUCs) Pinnacle Canyon Celeron SKU: Intel NUC Kit NUC5CPYH Pinnacle Canyon Pentium SKU: Intel NUC Kit NUC5PPYH Grass Canyon Pentium SKU: Intel NUC Kit NUC5PGYH 1 X 8 USB header PN # GR-LID-100
