for Raspberry Pi High-Precision AD HAT with 32-Bit ADC ADS1263 10-Ch Compatible with Raspberry Pi 2 3 4 Series and Jetson Nano AXYGStudy

Overview High-Precision AD HAT for Raspberry Pi, ADS1263 10-ch 32-bit ADC Adopts ADS1263 chip, low noise, low temperature drift, 10-ch 32-bit high precision ADC (5-ch differential input), 38.4kSPS Max sampling rate with embedded 24-bit auxiliary ADC, internal ADC test signal, IDAC, 2.5V internal reference voltage, 8x multiplexing GPIO, PGA (32 times Max) Onboard AD header input, compatible with Waveshare sensor pinout, for connecting sorts of sensor modules Onboard AD screw terminal input, allows connecting analog signal and analog power supply, general purpose interface Onboard control header, make it easy to control the module by other hosts in additional to Raspberry Pi Three-wire RTD (resistor temperature detector) circuit, enabled by soldering 0R resistor Package Contains High-Precision AD HAT x1 RPi screws pack (2PCS) x1 For more details you may need to know, pls firstly send me message via Amazon, I will then send attached document including User Guide for you, thank you for patience.;D
