DUTTY400WDC-DC high Power Constant Voltage Constant Current Boost Power Supply Module LED Boost Drive Notebook Battery Charger

Product parameters: ?Module name?400W boost constant current module [Module properties]: non-isolated boost module (BOOST) ?Input voltage?: DC8.5V-50V [Input current]: 1 (MAX) more than 8A, please strengthen heat dissipation [Static working current]: 10mA (when 12V rises to 20V, the higher the output voltage, the higher the static current will increase) [Output voltage]: 10-60V continuously adjustable (default output 19V shipment) [Output current]: If 12A MAX exceeds 7A, please strengthen the heat dissipation (related to the input and output pressure difference, the larger the pressure difference, the smaller the output current) ?Constant current range?: 0.2-12A [Output power]: = input voltage*10A, such as: input 12V*=60W, input 24V*=120W, input 36V*=180W, input 48V*=240W, [Working temperature]: -40~+85 degrees (please strengthen heat dissipation when the ambient temperature is too high) ?Working frequency?: 150KHz [Conversion efficiency]: 96% (efficiency is related to input, output voltage, current, and differential pressure) [Overcurrent Protection]: Yes (The input exceeds 1, the output voltage will be automatically reduced, and there is a certain range of error.) [Input reverse connection protection]: None, (If you need a higher reverse connection current, please connect a diode in series with the input) [Installation method]: 4 2.5mm screw holes ?Wiring method?: Wiring output [module size]: length 67mm width 48mm height 28mm [Module unit weight]: 60 grams Products include 400WDC-DC high power constant voltage constant current boost power supply module*1
