DieseRC 3pcs Relay Receivers with 2 Transmitters 433Mhz Wireless Remote Control Switch Radio Frequency DC 12V 1 Channel Passive Output Relay Controller

Package include: 3x Relay Receiver boards (included shell) 2x Transmitters (included battery) 1x Product manual Parameter: -Receiver Working voltage: DC 12V -Input/Output vlotage: 1~250V -Quiescent Current: <5MA -Max current: 10A -RF frequency: 433MHz -Working temperature: -30~+80 -Receiving Sensitivity: >97dbm -Amount of storage remote controls: 20 pieces -Support encoding: 1527 Leaning code -RF Operating mode: ASK superheterodyne wireless reception -Receiving range: Open space is more than 50 meters -Pin: COM,NO,NC - Operating mode: Momentary /Toggle/ Latched/ Delay Mode -Battery: 2x CR2016(included) Usage(Operation Mode): Momentary Mode: 1. Press and hold button “ON”, relay will turn on; 2. Release the button, this relay will turn off. Toggle Mode: 1. Press button “ON”, relay will turn on; 2. Press button “ON” again, this relay will turn off. Latched mode: 1. Press button “ON”, relay will turn on; 2. Press button “OFF”, this relay will turn off. Delay mode: 1. Press button “ON”, relay will turn on; 2. Release the button, this relay will turn off after 5(or 10/15/20) seconds. Reset: Press the learning button (on the Receiver) 8 times. succeed. Note: After reset all the remote controls cannot work anymore. Setup 1. Press the learning button (once for Momentary mode, twice for Toggle mode, 4/5/6/7 times for delay 5/10/15/20 seconds mode). Wait for 3 seconds; 2. Press button “ON” . Succeed. Setup latched mode 1. Press the learning button 3 times. Wait for 3 seconds; 2. Press button “ON” . 3. Press button “OFF” . Succeed. Note: This item has already been set up in Latched mode. If you want to change the operation mode please reset it firstly.
