Gravity: MOSFET Power Controller
Introduction
In most Arduino projects, relays are the first choice to drive some large current device. It requires a certain amount of current to drive the internal coil to pick-up contact. But for some MCU, like Intel Edison, Intel joule, lilypad, Raspberry Pi and other microcontroller with limited amount of current GPIO, its hard to drive one or more relays simultaneously.
The Gravity MOSFET power controller is a MOSFET relay which can drive a large current device with limited amount of current.
Specification
VIN Operating Voltage: 5V-36V
VIN Operating Current: 0A-20A (Suggest external heat sink when the current over 10A )
Logic Operating Voltage: 3.3~10V
Logic Control Signal: 3.3~10V
Switching Frequency: 0-1KHz
Switching Character: T(on)=20us/T(off)=50us
Operating Temperature: -55?-155?
Interface Type: PH2.0-3P
Dimension: 44*32 mm/ 1.73*1.26 inches
Shipping list
1 x Gravity: MOSFET Power Controller
1 x Gravity Digital Sensor Cable
DFROBOT Gravity MOSFET Power Controller Module as MOSFET Relay or Driver Compatible with Arduino Raspberry Pi and Other Microcontroller
Was:
$99.10
Now:
$49.55
- SKU:
- TE265420
- UPC:
- 6959420911509
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
