DC 12V 12-Channel 10A Relay Control Module Low Level Trigger Red and Blue Indicators for Arduino

1, The module uses genuine high quality relay, normally open interface maximum load: AC 250V / 10A, DC 30V / 10A;
2, Using high-power high-voltage transistor 2907A, strong driving capability, stable performance; trigger current 5mA;
3, Module working voltage DC 12V;
4, The relay pull-low, the module contains a current-limiting resistor, low-level can be DC-, microcontroller I / O port can also be set low; 5, Fault-tolerant design, even if the control line is broken, the relay will not move;
6, Power indicator (red), 12 relay status indicator (blue);
7, User-friendly interface design, all interfaces can be directly connected leads, very convenient;
8, Module size: 12mm x 9mm x 18mm / 4.72 x 3.54 x 0.71 inch (L * W * H);
9, Weight: 39 g / 0.086lb;
10, With 4 fixing bolt holes for easy installation.

Module interface
Module control side:
All interfaces can be directly connected , user-friendly
1, DC +: DC 12V
2, DC-: DC -
3, CL1-CL12: relay control interface, the corresponding low level pull the relay.

Relay output:
12-wire interface (K1 to K12), all interfaces can be directly connected to the wiring, user-friendly
1, NO1 - NO12: relay normally open interface;
2, COM1 - COM12: relay common interface;
3, NC1 - NC12: normally closed relay interface.
Package Included:
1*DC 12V 12-Channel Relay Control Module
