DESCRIPTION?
The VEML6075 senses UVA and UVB light and incorporates photodiode, amplifiers, and analog / digital circuits into a single chip using a CMOS process.
When the UV sensor is applied, it is able to detect UVA and UVB intensity to provide
a measure of the signal strength as well as allowing for UVI measurement.
The VEML6075 provides excellent temperature compensation capability for keeping the output stable under changing temperature.
VEML6075's functionality is easily operated via the simple command format of I2C (SMBus compatible) interface protocol. VEML6075's operating voltage ranges from 1.7V to 3.6V. VEML6075 is packaged in a lead (Pb)-free 4 pin OPLGA package which offers the best market-proven reliability.
Features:
Dimensions (L x W x H in mm): 2.0 x 1.25 x 1.0
Integrated modules: ultraviolet sensor (UV), and signal conditioning IC
Converts solar UV light intensity to digital data
Excellent UVA and UVB sensitivity
Reliable performance of UV radiation
measurement under long time solar UV
exposure:
16-bit resolution per channel
UVA and UVB individual channel solution
Low power consumption I2C protocol (SMBus compatible)
interface:
Package: OPLGA
Temperature compensation: -40 °C to +85 °C
Output type: I2C bus
Operation voltage: 1.7 V to 3.6 V
Material categorization: for definitions of compliance
APPLICATIONS?
Handheld device
Notebook
Consumer device
Industrial and medical application
Note:
The installation of electronic modules requires basic knowledge and requires a certain electronic professional foundation and hands-on ability. Please purchase carefully!
Manual measurement, with small error. Please check size in detail before purchase.
Real colors may slightly differ from the pictures, as it depends on specific monitor set
