CNLINKO DH24 Aviation Connector M24 Male Plug with Female Socket Waterproof Metal Thread Panel Connector 19 Pins for AC DC Signal LED Lighting Equipment

Specifications for 3pin, 4pin: Cable specification: 2.5m?-4m?/14-12AWG Diameter range: ?8mm??12mm Contact diameter ?number: ?3.0x3 / ?3.0x4 Rated Current (A): 20A Operating voltage (AC.V.rms): 500V Contact resistance: <5m? Temperature rise: 20A contact temperature below 30?, 25A ......40??, 30A......50?? Withstanding Voltage (AC.V) 1 minute: 2500V Specifications for 10pin, 12pin: Cable specification: 2.5m?-4m?/14-12AWG Diameter range: ?8mm??12mm Contact diameter ?number: ?3.0x10 / ?3.0x12 Rated Current (A): 10A Operating voltage (AC.V.rms): 400V Contact resistance: <2.5m? Temperature rise: 10A contact temperature below 30?, 12A ......40??, 15A......50?? Withstanding Voltage (AC.V) 1 minute: 2500V Specifications for 19pin, 24pin: Cable specification: 2.5m?-4m?/14-12AWG Diameter range: ?8mm??12mm Contact diameter ?number:?3.0x19/ ?3.0x24 Rated Current (A): 5A Operating voltage (AC.V.rms): 150V Contact resistance: <5m? Temperature rise: 5A contact temperature below 30?, 7A ......40??, 10A......50?? Withstanding Voltage (AC.V) 1 minute: 1500V Insulation resistance: ?500M? Protection level: IP65/IP67 Durability: ?500 times Working temperature: -40??80? Connecting mode: Plug unplug Housing, the insulating parts: High-performance engineering plastics Hardware: Zinc Alloy (pearl hard chrome) Copper needles: Copper alloy (gold-plated) Waterproof circle: Silica gel Flammability rating: UL94-V0 Package list: 1 male plug +1 female socket
