BTMETER BT-770M Manual Ranging Digital Multimeter is the perfect DIY hand tool for troubleshoot electrical problems in a wide
array of industrial and household devices such as electronic equipment, motor controls, domestic appliances, power
supplies and wiring systems.
It's tough, lightweight but durable and very easy to operate. It can measure AC/DC current, AC/DC voltage, resistance,
continuity(buzzer), transistor and diodes with a very high degree of accuracy. CATIII1000V certification make sure working safety.
After years of observation and research , we hope new design substitutable fixed mode can help users more convenient
work:Fix the meter by magnet for adsorbed on the metal, convenient for both hands to carryout the measurement job.
The color-coded LEDs allow you know Voltage on/off .Includes attachable test leads, holders and stand for hands free use
and features protective rubber corner guards for drop protection.
temperature probe and User Manual.
Specifications:
Range Selection: Manual Ranging
Max Display: 6000
Sample Rate: 3 times/s
DC Voltage: 600mV~ 1000V
AC Voltage: 6V~ 750V
DC Current: 60uA~ 20A
AC Current: 6mA~ 20A Resistance: 600ohm~ 60Mohm
Capcitance:9.999Nf~99.99mF ( Auto range )
Frequency:9.999Hz~9.999Mhz ( Auto range )
Duty cycle:0.1%~99.9%
Temperature:-20?~-1000?-4?~1832?
Auto LCD Backlight: Yes
Overload protection: Yes
Data Hold: Yes
Diode Test: Yes
Low Battery indication: Yes
Auto power off
?/??yes
True RMS: YES
Relative Value: yes
Continuity Test: Yes
Non Contact AC Voltage (NCV) detection
Self-Locking Protection
Functions witch indicator lamp
