Bosmutus OBD2 ELM327 USB V1.5 OBDII Scanner, EOBD/OBDii Code Reader, OBD-II Engine System Diagnostic Tools (More Than 3000 Database Code) - USB for Android/Windows

ELM327 USB V1.5 ODB2 Scanner. Supported Protocols: 1.SAE J1850 PWM (41.6 Kbaud) 2.SAE J1850 VPW (10.4 Kbaud) 3.ISO9141-2 (5 baud init, 10.4 Kbaud) 4.ISO14230-4 KWP (5 baud init, 10.4 Kbaud) 5.ISO14230-4 KWP (fast init, 10.4 Kbaud) 6.ISO15765-4 CAN (11bit ID, 500 Kbaud) 7.ISO15765-4 CAN (29bit ID, 500 Kbaud) 8.ISO15765-4 CAN (11bit ID, 250 Kbaud) 9.ISO15765-4 CAN (29bit ID, 250 Kbaud) Diagnostic Tool Functions: 1: Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database). 2: Clear trouble codes and turn off the MIL ("Check Engine" light) 3: Display current sensor data, including: ? Engine RPM ? Calculated Load Value ?Coolant Temperature ? Fuel Pressure ? Fuel System Status ? Vehicle Speed ? Short Term Fuel Trim ? Long Term Fuel Trim ? Intake Manifold Pressure ? Timing Advance ? Intake Air Temperature ? Air Flow Rate ? Absolute Throttle Position ? Oxygen sensor voltages / associated short term fuel trims ? Fuel System status ? Many others OBD2 Reader Specifications: Communication: USB Interface Master Chip: ST Driver IC: PL2303 Support System: Windows Working Voltage: 9v ~ 16v Working Current: 15mA Standby Current: 0mA Operating temperature: -40 ? ~ 85 ? Working Humidity: less than 60% Size: 45mm * 25mm * 75mm?Cable Length 1.5M? Package List: 1pc x Mini OBD2 USB Diagnostic Cable 1pc x Manual
