ATS48A-1Z Time Delay Relay Module, Digital LCD Display Adjustable Cycle Time Delay Relay Control Component-DC24V-

Specification: Condition: 100% Brand New Item Type: Time Relay Material: Plastic Power Supply Voltage: 85-110% of rated voltage Power Consumption: ?5W Contact Capacity: AC220V5A DC30V5A (Resistive) Mechanical Life: ?100,000 Times Electrical Life: ?100,000 Times Ambient Temperature: -10?~+50? Altitude: <2000m Delay Control Precisions: ?0.3%±0.05 Seconds Features: A set of power-on delay contact output, with reset and pause functions Display Mode: LED digital tube displays the timing value in different areas Delay Range: 0.01 second -99 hours and 99 minutes Installation Method: Panel Type: Hole Size: Approx. 45 x 45mm / 1.8 x 1.8in Device Type: Hole Distance: Approx. 33mm / 1.3in, the mounting screw is 2-M4×20mm / 0.8in Rail Type: Approx. 35mm / 1.4in standard rail Package List: 1 x Time Relay Note: 1. Please allow slight error due to manual measurement. Thanks for your understanding. 2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.
