2pcs E-Simpo G24d 2 Pin 11W LED PL Plug in Bulb Horizontal Recessed Rotatable 1000-1200lm PLC CFL 2U PL-C 26W Equivalent Replacement 180D Beam-Need Throw Ballast- -Warm White G24D Base 2-Pin 21mm-

2pcs E-Simpo G24d 2 Pin 11W LED PL Plug in Bulb Horizontal Recessed Rotatable 1000-1200lm PLC CFL 2U PL-C 26W Equivalent Replacement 180D Beam(Need Throw Ballast) (Warm White, G24D Base 2-Pin 21mm) Specification Input Voltage: 85-300V AC Power: 11W LED, Can replace CFL G24d 2-Pin 26W PLC Lamp Non-Dimmable CRI>82 Horizontal Plug-in Bulb, 180degree view angle Base: G24d 2-Pin, compatible for G24d-1, G24d-2, G24d-3 Brightness: 11W 1000-1200LM; Color Temperature: Warm White 3000-3500k Application: 11W is used to Replace PL-C 26W 2U CFL. which are widely used in Use in Recessed/Surface-mounted Downlights, Recessed Cans, Table/Desk Lamps, Portables, Pendant Lamps, Ceiling Fixtures, Wall Washers, Wall Sconces, Family Rooms, Living Rooms, Kitchens, Dining Rooms, and Porches. Note: Plug and play for inductive ballast fixture, but remove ballast required for electronic ballast. THE ELECTRONIC BALLAST IN YOUR FIXTURE MUST BE REMOVED OR BYPASSED FOR THESE ADAPTERS TO FUNCTION PROPERLY. CONSULT AN ELECTRICIAN IF YOU ARE UNSURE. DO NOT OPERATE A LED BULB WITH A BALLAST IN THE FIXTURE,Otherwise the LED Lamp witll get flicking, burnt, smell, damaged. How to bypass the ballast? 1. Turn Off the Power. 2. Find the Ballast. Usually it is embeded inside the ceiling fixture. Pls pull off the existing PL lamp, reflector. Leave wire in junction box. and find the ballast. 3. Normally, the Ballast has a black and white wire on the input side (AC input side, 100V -120V for North America). It also has two red and two blue output wires. To bypass this ballast, please cut all the Input and output wires, so total 6 wires cut. 4. Then, you can connect the two red wires to the black wire. 5. Next, connect the two blue wires to the white wire. now ballast is bypassed.
