2.23inch OLED Display HAT, 128x32 Pixels SPI/I2C Interface Embed SSD1305 Driver for Raspberry Pi 4B/3Bplus/3B/2B/Zero/Zero W/Zero WH and Jetson Nano

2.23inch OLED display HAT for Raspberry Pi, 128×32 pixels, SPI/I2C interface Overview This is an OLED display HAT for Raspberry Pi, 2.23inch diagonal, 128×32 pixels, with embedded SSD1305 driver, communicating via SPI or I2C interface. Trying to add a control interface for your Pi? This compact display would be the ideal choice. Features Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards, Jetson Nano Optional interfaces: SPI (default), or I2C, configured via onboard resistor Brings control pins for host boards like Arduino/STM32 Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/Arduino/STM32) Development Resources https://www.waveshare.com/wiki/2.23inch_OLED_HAT Specifications Driver: SSD1305 Interface: SPI / I2C Display size: 2.23inch diagonal Display color: white Resolution: 128×32 Viewing angle: >160° Power supply voltage: 3.3V/5V Logic level: 3.3V Package Content 1.2.23inch OLED HAT x1 2.RPi screws pack (2pcs) x1
